Redesigned for today’s high-performance bar environments, the Next Generation FDD Series Direct Draw Beer Coolers deliver reliable “ICE COLD” draft performance in tight spaces—even under extreme ambient conditions up to 100°F. Built with a front-breathing design and side-mounted evaporator, these units are the industry benchmark for keg cooling, space efficiency, and tap tower airflow.

Key Features:

Front-Breathing Design: Engineered for built-in or flush-install applications—ideal for tight bar layouts or enclosed counters.

100°F Rated Performance: Capable of maintaining temperatures between 33°F and 38°F, even in demanding environments.

Optimized Draft Tower Cooling: Unique forced-air cooling system pushes cold air directly into the 3" diameter polished stainless steel draft towers—providing more consistent and colder pours with more taps per tower than competing models.

Heavy-Duty Construction:

18-gauge stainless steel top

Stainless steel interior walls with NSF-approved coved floor

Reinforced bottom door frame and polymer “dunnage-style” floor to support kegs and extend cabinet life

Field Interchangeable Doors: Easily switch between solid or glass doors in the field—adaptable to changing service or display needs.

Service-Friendly Refrigeration:

Left-mounted compressor on slide-out rail system

Large fan motor and blades for improved airflow

Rear-located drain inside compressor housing keeps it out of customer view

Automatic condensate evaporation—no floor drain required

Lighting & Electrical:

Interior LED Lighting under mullion—shielded for protection during loading/unloading

Supplied with 8’ power cord and NEMA 5-15P plug

Refrigeration System:

Self-contained capillary tube system

Environmentally friendly R-134a refrigerant

Side-mounted evaporator coil

Foamed-in-place 2” Ecomate® CFC-Free polyurethane insulation

Standard CO₂ Valve Configuration:

36” Model: (1) 2-way CO₂ valve

59” & 69” Models: (1) 3-way CO₂ valve

79” & 95” Models: (1) 4-way CO₂ valve

Options & Accessories:

Low-profile or heavy-duty casters with reinforced rails

6” adjustable stainless steel legs

Single or double draft towers

220V / 50Hz / 1-phase option available

Models & Finishes:

Standard black vinyl front, sides, and back

(S) models feature stainless steel front and sides

Galvanized back panel

Warranty:
3-year parts & labor warranty + 2 additional years on compressor.
